| nominal diameter | dn15~300 |
| nominal pressure | pn1.0~1.6mpa ansi 150lb |
| medium temperature | -30~150℃ |
| connection method | flange type |
| valve bonnet type | standard type |
| body material | wcb f46 or pfa、cf8 f46 or pfa |
| core material | 20 f46 or pfa、304 f46 or pfa |
| seal material | ptfe |
| flow characteristics | quick open |
| leakage – soft seal | ansi class vi |
zshof series “o” type fluorine lined ball valve is a full-diameter ball valve structure. using a special moulding process, the inner wall of the valve body and the ball core lining fluorine plastic can resist the corrosion of strong acid and alkali medium, mainly used to cut off or connect the corrosive medium in the pipeline, and can be used for the regulation and control of the fluid; the sphere is the integrated design of the valve stem eliminates the difference in rotation angle; the metal limit structure at the connection between the main and auxiliary valve body, the valve body and the stuffing box, makes the valve seat sealing ring reasonably preloaded and limited, and maintains the torque stability; high-performance dual-piston rack and pinion structure, high transmission efficiency, compact structure or electronic electric actuator.
