| nominal diameter | dn15~500 |
| nominal pressure | pn1.6~16.0mpa ansi 150~900lb |
| medium temperature | -29~425℃ |
| connection method | flange type |
| valve bonnet type | standard type |
| body material | wcb、cf8、cf8m、cf3m |
| core material | 304、316、316l、304 wc、316l wc |
| seal material | c-ptfe、ppl、304 wc、316l wc、 |
| flow characteristics | quick open |
| leakage – hard seal | ansi class v、vi |
| leakage – soft seal | ansi class vi |
zsho series “o” on-off ball valve is a two-piece ball valve structure. the valve body is composed of main and auxiliary parts. the valve seat has small wear, excellent sealing, long service life and extremely strong cutting performance. the core adopts full diameter, large rated flow coefficient and small flow resistance. soft seal seat seal material is carbon fiber reinforced ptfe; hard seal ball core, seal surface treated with tungsten carbide spray, with strong wear resistance. seat-retaining structure design maintains the stability of the torque; the bottom-mounted stem anti-fly-out design, the valve seat seal fireproof, anti-static design.
